포스장비
세계 최고의 제품을 제공하고 신뢰할 수
있는 파트너로 성장하겠습니다.

HW-3000

주요기능 및 제품특징

  • · 모니터 앞면의 생활방수 기능 반영
  • · 쉽고 빠른 유지보수를 위한 Toolless구조
  • · 인텔셀러론 프로세서(1037U) 채용
  • · 듀얼모니터(9.7") 지원


    • 이전
    다음
    이전
    다음

    사양
    항목 사양
    CPU & Chipset · Intel® Celeron® 1037U, Dual Core (1.8GHz, 2M Cache)
    · Intel® NM70
    Memory · 2GB DDR3 1333MHz, SoDIMM (up to 8GB)
    HDD · 2.5", SATA-III 320GB↑or SSD 32GB↑
    · SATA-II m-SATA 32GB↑ Support IDE/ACHI mode
    Display · 15", 1024 X 768, 24Bit, Luminance : 250 cd/㎡, Backlight : LED
    · 15", 5-wire Resistive Touch panel
    VGA · 1EA VGA(DSUB15), Intel® HD Graphics 2500
    LAN · 2EA (Intel® Gigabit LAN)
    Serial(RS-232C) · 4EA (DSUB-9p x 3EA / RJ-45 x 1EA), Support Powered COM2/3 (select by BIOS)
    Parallel(LPT) -
    PS/2 · 2EA (Keyboard / Mouse)
    USB · 4EA (I/O) (USB2.0), 2EA (Front) (USB2.0)
    Audio · Line-Out, MIC-In, Realtek ALC269 HD2.1 Audio
    Speaker · 1 EA (1W) (Internal Speaker)
    Expansion Interface · 1 EA PCIe Socket, 1 EA Full Size Mini PCIe Socket (m-SATA)
    Cooler & FAN · Fanless
    Power Adaptor · 60[W] Adaptor, Input AC 100~240V/50~60HZ, DC 12V/5A
    Dimension(mm) ·  364(W) x 332(H) x 200(D) (Normal Angle, With Stand)
    Weight · 7.3kg
    OS supported · POSReady2009 / POSReady7 / Win8.1 Industry / WinXP / Win7 / Win8.1 / Linux
    OS · POSReady2009 / POSReady7 / Win8.1 Industry / WinXP / Win7 / Win8.1
    Wall Mount · Fixed Type / Swivel Type (75x75, 100x100mm VESA)
    Touch Panel · 15", 5-Wire Resistive, eGalax Controller(Serial I/F), Bezel type / Bezelless type
    Dual Display · 9.7", TFT-LCD, 1024x768, LED panel (Touch), 15", TFT-LCD, 1024x768, LED panel
    MSR · ISO Track2 / Track 1&2 / Track 1&2&3
    iButton · Probe(USB), Dallas key
    Smart IC Card · IC Card Reader(USB), EMV Level#1
    Barcode Scanner · USB Module(Internal) type, 1D, 2D
    NFC · Serial Module(Internal) type, SCSPRO NFM1V0
